Bag Code Selection

Filter Media	Nominal Micron Rating	Bag Size	Bag Construction	Ring Material	Ring Construction
Monofilament     (NYLON/POLYESTER)	1,5,10,25,50,75,80,100,125,150, 200,250	P1S	S-Sewn          W-Welded	S-Stainless Steel Z-Zinc plated P-Plastic PE/PP	S-Sewn          W-Welded
		P2S
	25,50,75,80,100,125,150,200,250, 300,400,600,800,1250,2500	P3S
		P4S
Example: NYLON	100		S	S	S

Filter bag data

Bag Size	Filter Area(M2)	Volume(Litre)	Max. Flow(M3/H)
P1S	0.25	8	20
P2S	0.5	17	40
P3S	0.09	1.3	6
P4S	0.16	2.5	12


Chemical compatibility chart

Filter media	Temp. (℃)	Aqueous Medium	Aliphatic Solvents	Aromatic Solvents	Alkaline	Strong Alkaline	Acid	Strong Acid	Oils
Polypropylene(PP)	90-110	OK	OK	OK	OK	×	OK	OK	OK
Polyester(PET)	130-150	OK	OK	OK	OK	×	OK	OK	OK
Nylon Monofilament(NMO)	140-160	OK	OK	OK	OK	OK	×	×	Fair
