PP filter housing

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
1(5#)	0.6	23	0.23	1-500	DN50	PP	5-65°C
1(5#)	0.6	23	0.23	1-500	DN50	PPR	5-90°C

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
1(2#)	0.6	40	0.5	1-500	DN50	PP	5-65°C

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
1(2#)	0.6	40	0.5	1-500	DN50	PP	5-65°C
1(2#)	1	40	0.5	1-500	DN50	PPH	5-65°C

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
2	0.4	90	1	1-500	DN100	PP	5-65°C

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
3	0.4	135	1.5	1-500	DN100	PP	5-65°C

Bag type	Design pressure (MPa)	Max flow rate (M3/H)	Filter area (M2)	Micron(μ)	Diameter for Inlet and outlet	Material	Tem°C
4	0.4	180	2	1-500	DN100	PP	5-65°C
